How to fix OOMKilled (exit code 137) Kubernetes error

192 Views

What is OOMKilled (exit code 137)

The OOMKilled error, also indicated by exit code 137, means that a container or pod was terminated because they used more memory than allowed. OOM stands for “Out Of Memory”.

Kubernetes allows pods to limit the resources their containers are allowed to utilize on the host machine. A pod can specify a memory limit – the maximum amount of memory the container is allowed to use, and a memory request – the minimum memory the container is expected to use.

If a container uses more memory than its memory limit, it is terminated with an OOMKilled status. Similarly, if overall memory usage on all containers, or all pods on the node, exceeds the defined limit, one or more pods may be terminated.

You can identify the error by running the kubectl get pods command—the pod status will appear as Terminating.

NAME        READY    STATUS       RESTARTS    AGE
my-pod-1    0/1      OOMKilled    0           3m12s

We’ll provide a general process for identifying and resolving OOMKilled. More complex cases will require advanced diagnosis and troubleshooting, which is beyond the scope of this article.

How Does the OOM Killer Mechanism Work?

OOMKilled is actually not native to Kubernetes—it is a feature of the Linux Kernel, known as the OOM Killer, which Kubernetes uses to manage container lifecycles. The OOM Killer mechanism monitors node memory and selects processes that are taking up too much memory, and should be killed. It is important to realize that OOM Killer may kill a process even if there is free memory on the node.

The Linux kernel maintains an oom_score for each process running on the host. The higher this score, the greater the chance that the process will be killed. Another value, called oom_score_adj, allows users to customize the OOM process and define when processes should be terminated.

Kubernetes uses the oom_score_adj value when defining a Quality of Service (QoS) class for a pod. There are three QoS classes that may be assigned to a pod:

  • Guaranteed
  • Burstable
  • BestEffort

Each QoS class has a matching value for oom_score_adj:

Quality of Service oom_score_adj
Guaranteed -997
BestEffort 1000
Burstable min(max(2, 1000—(1000 * memoryRequestBytes) / machineMemoryCapacityBytes), 999)

Because “Guaranteed” pods have a lower value, they are the last to be killed on a node that is running out of memory. “BestEffort” nodes are the first to be killed.

A pod that is killed due to a memory issue is not necessarily evicted from a node—if the restart policy on the node is set to “Always”, it will try to restart the pod.

To see the QoS class of a pod, run the following command:

Kubectl get pod -o jsonpath=’{.status.qosClass}’

To see the oom_score of a pod:

  1. Run kubectl exec -it /bin/bash
  2. To see the oom_score, run cat/proc//oom_score
  3. To see the oom_score_adj, run cat/proc//oom_score_adj

The pod with the lowest oom_score is the first to be killed when the node runs out of memory.

OOMKilled: Common Causes

The following table shows the common causes of this error and how to resolve it. However, note there are many more causes of OOMKilled errors, and many cases are difficult to diagnose and troubleshoot.

Cause Resolution
Container memory limit was reached, and the application is experiencing higher load than normal Increase memory limit in pod specifications
Container memory limit was reached, and application is experiencing a memory leak Debug the application and resolve the memory leak
Node is overcommitted—this means the total memory used by pods is greater than node memory Adjust memory requests (minimal threshold) and memory limits (maximal threshold) in your containers

OOMKilled: Diagnosis and Resolution

Step 1: Gather Information

Run kubectl describe pod [name] and save the content to a text file for future reference:

kubectl describe pod [name] /tmp/troubleshooting_describe_pod.txt

Step 2: Check Pod Events Output for Exit Code 137

Check the Events section of the describe pod text file, and look for the following message:

State:          Running
       Started:      Thu, 10 Oct 2019 11:14:13 +0200
       Last State:   Terminated
       Reason:       OOMKilled
       Exit Code:    137
       ...

Exit code 137 indicates that the container was terminated due to an out of memory issue. Now look through the events in the pod’s recent history, and try to determine what caused the OOMKilled error:

  • The pod was terminated because a container limit was reached.
  • The pod was terminated because the node was “overcommitted”—pods were scheduled to the node that, put together, request more memory than is available on the node.

Step 3: Troubleshooting

If the pod was terminated because container limit was reached:

  • Determine if your application really needs more memory. For example, if the application is a website that is experiencing additional load, it may need more memory than originally specified. In this case, to resolve the error, increase the memory limit for the container in the pod specification.
  • If memory use suddenly increases, and does not seem to be related to application loads, the application may be experiencing a memory leak. Debug the application and resolve the memory leak. In this case you should not increase the memory limit, because this will cause the application to use up too many resources on the nodes.

If the pod was terminated because of overcommit on the node:

  • Overcommit on a node can occur because pods are allowed to schedule on a node if their memory requests value—the minimal memory value—is less than the memory available on the node.
  • For example, Kubernetes may run 10 containers with a memory request value of 1 GB on a node with 10 GB memory. However, if these containers have a memory limit of 1.5 GB, some of the pods may use more than the minimum memory, and then the node will run out of memory and need to kill some of the pods.
  • You need to determine why Kubernetes decided to terminate the pod with the OOMKilled error, and adjust memory requests and limit values to ensure that the node is not overcommitted.

When adjusting memory requests and limits, keep in mind that when a node is overcommitted, Kubernetes kills nodes according to the following priority order:

  1. Pods that do not have requests or limits
  2. Pods that have requests, but not limits
  3. Pods that are using more than their memory request value—minimal memory specified—but under their memory limit
  4. Pods that are using more than their memory limit

To fully diagnose and resolve Kubernetes memory issues, you’ll need to monitor your environment, understand the memory behavior of pods and containers compared to the limits, and fine tune your settings. This can be a complex, unwieldy process without the right tooling.

Solving Kubernetes Errors Once and for All with Komodor

The troubleshooting process in Kubernetes is complex and, without the right tools, can be stressful, ineffective and time-consuming. Some best practices can help minimize the chances of things breaking down, but eventually something will go wrong—simply because it can.

This is the reason why we created Komodor, a tool that helps dev and ops teams stop wasting their precious time looking for needles in (hay)stacks every time things go wrong.

Acting as a single source of truth (SSOT) for all of your k8s troubleshooting needs, Komodor offers:

  • Change intelligence: Every issue is a result of a change. Within seconds we can help you understand exactly who did what and when.
  • In-depth visibility: A complete activity timeline, showing all code and config changes, deployments, alerts, code diffs, pod logs and etc. All within one pane of glass with easy drill-down options.
  • Insights into service dependencies: An easy way to understand cross-service changes and visualize their ripple effects across your entire system.
  • Seamless notifications: Direct integration with your existing communication channels (e.g., Slack) so you’ll have all the information you need, when you need it.

If you are interested in checking out Komodor, use this link to sign up for a Free Trial.
